Name: IRAS 19343+2926, Minkowski's Footprint
Description: Planetary Nebula
Position (J2000): RA 19h 36m 18.79s Dec 29° 32' 52.34"
Constellation: Cygnus
Distance: 8000 light years
Field of view: 0.56 x 0.43 arcminutes
Orientation: North is 25.7° right of vertical
Image Credit: ESA/Hubble & NASA
Release date: July 11, 2011
Click the image to buy a print


The NASA/ESA Hubble Space Telescope has been used to capture a striking image of a rare astronomical phenomenon called a protoplanetary nebula. This particular example, called Minkowski's Footprint, also known as Minkowski 92, features two vast onion-shaped structures either side of an ageing star, giving it a very distinctive shape.

Protoplanetary nebulae like Minkowski's Footprint have short lives, being a preliminary stage to the more common planetary nebula phase. In the middle of the image is a star, soon to be a white dwarf, puffing out material due to intense surface pulsations. Charged particle streams, called stellar winds, are shaping this gas into the interesting shapes that Hubble allows us to see.

Technically speaking Minkowski's Footprint is currently a reflection nebula as it is only visible due to the light reflected from the central star. In a few thousand years the star will get hotter and its ultraviolet radiation will light up the surrounding gas from within, causing it to glow. At this point it will have become a fully fledged planetary nebula.

The processes behind protoplanetary nebulae are not completely understood, making observations such as this even more important. Hubble has already conducted sterling work in this field, and is set to continue.

The image was obtained with the Hubble's Wide Field Planetary Camera 2. The picture has been made from many exposures through four different color filters. Light from ionized oxygen has been colored blue (F502N), light passing through a green/yellow filter (F547M) is colored cyan, light from atomic oxygen is colored yellow (F631N) and light from ionized sulphur is colored red (F673N). The total exposure times per filter were 2080 sec, 960 sec, 2080 sec and 1980 sec respectively and the field of view is only about 36 arcseconds across.
