Name: SNR 0509-68.7, N103B
Description: Supernova Remnant
Position (J2000): RA 5h 8m 51.49s Dec -68° 44' 6.49"
Constellation: Dorado
Distance: 150,000 light years
Field of view: 2.37 x 2.30 arcminutes
Orientation: North is 67.7° right of vertical
Image Credit: ESA/Hubble, NASA
Release date: March 30, 2017
Click the image to buy a print
+
—————————————————————————————————————————————————

ABOUT THIS IMAGE:

This image, taken with the NASA/ESA Hubble Space Telescope, shows the supernova remnant SNR 0509-68.7, also known as N103B (top of the image). N103B was a Type Ia supernova, located in the Large Magellanic Cloud - a neighbouring galaxy of the Milky Way. Owing to its relative proximity to Earth, astronomers observe the remnant to search for a potential stellar survivor of the explosion.

The orange-red filaments visible in the image show the shock fronts of the supernova explosion. These filaments allow astronomers to calculate the original centre of the explosion. The filaments also show that the explosion is no longer expanding as a sphere, but is elliptical in shape. Astronomers assume that part of material ejected by the explosion hit a denser cloud of interstellar material, which slowed its speed. The shell of expanding material being open to one side supports this idea.

The gas in the lower half of the image and the dense concentration of stars in the lower left are the outskirts of the star cluster NGC 1850, which has been observed by Hubble in the past [s0125]


Search for Stellar Survivor of a Supernova Explosion

A group of astronomers used Hubble to study the remnant of the Type Ia supernova explosion SNR 0509-68.7 - also known as N103B (seen at the top). The supernova remnant is located in the Large Magellanic Cloud, just over 160 000 light-years from Earth. In contrast to many other Supernova remnants N103B does not appear to have a spherical shape but is strongly elliptical. Astronomers assume that part of material ejected by the explosion hit a denser cloud of interstellar material, which slowed its speed. The shell of expanding material being open to one side supports this idea.

The relative proximity of N103B allows astronomers to study the life cycles of stars in another galaxy in great detail. And probably even to lift the veil on questions surrounding this type of supernova. The predictable luminosity of Type Ia supernovae means that astronomers can use them as cosmic standard candles to measure their distances, making them useful tools in studying the cosmos. Their exact nature, however, is still a matter of debate. Astronomers suspect Type Ia supernovae occur in binary systems in which at least one of the stars in the pair is a white dwarf [1].

There are currently two main theories describing how these binary systems become supernovae. Studies like the one that has provided the new image of N103B - that involve searching for remnants of past explosions - can help astronomers to finally confirm one of the two theories.

One theory assumes that both stars in the binary are white dwarfs. If the stars merge with one another it would ultimately lead to a supernova explosion of type Ia.

The second theory proposes that only one star in the system is a white dwarf, while its companion is a normal star. In this theory material from the companion star is accreted onto the white dwarf until its mass reaches a limit, leading to a dramatic explosion. In that scenario, the theory indicates that the normal star should survive the blast in at least some form. However, to date no residual companion around any type Ia supernova has been found.

Astronomers observed the N103B supernova remnant in a search for such a companion. They looked at the region in H-alpha - which highlights regions of gas ionised by the radiation from nearby stars - to locate supernova shock fronts. They hoped to find a star near the centre of the explosion which is indicated by the curved shock fronts. The discovery of a surviving companion would put an end to the ongoing discussion about the origin of type Ia supernova.

And indeed they found one candidate star that meets the criteria - for star type, temperature, luminosity and distance from the centre of the original supernova explosion. This star has approximately the same mass as the Sun, but it is surrounded by an envelope of hot material that was likely ejected from the pre-supernova system.

Although this star is a reasonable contender for N103B's surviving companion, its status cannot be confirmed yet without further investigation and a spectroscopic confirmation. The search is still ongoing.

Notes:

[1] A white dwarf is the small, dense core of a medium-mass star that is left behind after it has reached the end of its main-sequence lifetime and blown off its outer layers. Our own Sun is expected to become a white dwarf in around five billion years.
