Name: Horseshoe Nebula, Lobster Nebula, M 17, Messier 17, Omega Nebula,      Swan Nebula
Description: Star Formation Nebula
Position (J2000): RA 18 20 25.97 Dec -16° 10' 37.34"
Constellation: Sagittarius
Distance: 5500 light years
Field of view: 4.91 x 4.91 arcminutes
Orientation: North is 0.1° right of vertical
Image Credit: ESO
Release date: September 14, 2000



More Images:  N1119  N1044  N0030  N0211g  N0925  N0313  N1201  N0211c
N1537
Click the image to buy a print
+
—————————————————————————————————————————————————

ABOUT THIS IMAGE:

This is a near-infrared, color-coded composite image of a sky field in the south-western part of the galactic star-forming region Messier 17. In this image, young and heavily obscured stars are recognized by their red color. Bluer objects are either foreground stars or well-developed massive stars whose intense light ionizes the hydrogen in this region. The diffuse light that is visible nearly everywhere in the photo is due to emission from hydrogen atoms that have (re-)combined from protons and electrons. The dark areas are due to obscuration of the light from background objects by large amounts of dust - this effect also causes many of those stars to appear quite red. A cluster of young stars in the upper-left part of the photo, so deeply embedded in the nebula that it is invisible in optical light, is well visible in this infrared image.

Technical information : The exposures were made through three filters, J (at wavelength 1.25 µm; exposure time 5 min; here rendered as blue), H (1.65 µm; 5 min; green) and Ks (2.2 µm; 5 min; red); an additional 15 min was spent on separate sky frames. The seeing was 0.5 - 0.6 arcsec. The objects in the uppermost left corner area appear somewhat elongated because of a color-dependent aberration introduced at the edge by the large-field optics. The sky field shown measures approx. 5 x 5 arcmin (corresponding to about 3% of the full moon). North is up and East is left.

Beautiful images of astronomical objects often contain a lot of scientifically interesting information. This image is a fine example of this old maxim. It provides a deep and unsually wide look into a giant star forming region in the Milky Way. It is known as Messier 17 (M 17), or the Omega, Swan, Horseshoe, or Lobster Nebula , because of its characteristic shape when photographed in visible light. It is located at a distance of approx. 5000 light-years (1.6 kpc), and is seen in the southern constellation of Sagittarius (The Archer), near the main plane of the Milky Way.

This impressive image was obtained by astronomers Leonardo Testi (Arcetri Astrophysical Observatory, Florence, Italy; p.t. Visiting Scientist at ESO-Chile) and Leonardo Vanzi (ESO-Chile) with the SOFI multi-mode instrument at the ESO 3.6-meter New Technology Telescope (NTT) at the La Silla observatory. The observations were made in the course of a research project that is aimed at the detection and study of the formation of massive stars, by means of near-infrared direct and spectral exposures with this instrument.

The new data offer a unique combination of a wide field-of-view, high sensitivity and excellent image quality. The goal of these particular observations was to identify massive stars that are in the act of formation in this area and to record their infrared spectra for a detailed physical study of these rather rare objects.

The formation of massive stars

It is now well established that the formation of stars in our galaxy, the Milky Way system, predominantly takes place in Giant Molecular Clouds. However, while low-mass stars are common and relatively easy to find in such clouds, it is much more difficult to find massive stars while they are in the very early stage of their evolution.

This is because massive stars are comparatively rare and pass through the different evolutionary phases much faster than low-mass and solar-like stars. They are usually found within dense stellar clusters, located at large distances from the Sun.

The earliest evolutionary stages of both low- and high-mass stars cannot be observed at visible wavelengths. This is due to the very heavy obscuration in that wavelength region by the dust in the parental molecular clouds. However, infrared and millimeter emission from these objects is able to penetrate the dust and thus allow us to investigate the complex processes that occur at the earliest phases of stellar evolution.

A search for massive stars in the formation stage

The best possible comprehension of this crucial stage of the stellar life cycle constitutes a key to the understanding of the formation and evolution of galaxies. And in this context, it is especially the massive stars with their powerful radiation fields, strong stellar winds and dramatic final interaction with the interstellar medium through supernova explosions that dominate the energetics of normal galaxies. Massive stars have much shorter lives (about 1 million years) than lighter solar-type stars (10 - 12,000 million years) and only they undergo such violent explosions at the end.

A most challenging question in current astrophysics is therefore concerned with the nature of the various physical processes that take place during the formation of massive stars. It is for instance still unclear whether massive stars form like lower-mass stars of the solar type do, i.e., by accretion of gas from the surrounding cloud during a progressive contraction process, or if they are rather the results of stellar collisions in dense clusters.

The only way to know is by finding the youngest massive stars and then to study them in detail by means of spectroscopic observations. At the same time, their immediate surroundings, e.g., the stellar population in the star-forming cluster of which they are members, must also be investigated before the full picture will emerge.

Massive stars in Messier 17

It is in this context that new infrared observations have been made of the inner regions of Messier 17. In the area to the south-west of the center of this nebula several objects appear very red - this clearly identifies them as very young stars.

An infrared spectrum of one of the reddest objects that was only detected at the longest wavelength (the Ks band), confirmed it as a massive star in its earliest evolutionary phase.

The spectrum shows a featureless "continuum" that rises steeply towards long wavelengths, exactly as expected for a star in the process of formation, deeply embedded in dust. It is easily distinguishable from stars that have already formed, since their spectra display several absorption features and rise towards shorter wavelengths instead.
